Orb-3 Aeration MixAir Self-Sinking Aeration Hose

Orb-3 Aeration MixAir Self-Sinking Aeration Hose

UPC: 845738003455
SKU: D630-250-25FTR
Type: Aeration Hose & Tubing
$29.31

Weighted tubing carries air between the compressor and the diffuser. Made to work in all weather, even the cold, self-sinking hose will provide many years of service. Due to its weight, it will not float and requires no added weights during installation. Installation is easy and quick, compared to non-weighted tubing which requires added weights to keep it down.

Inside Diameter (ID)
Length

Notify me when back in stock

Use for:

  • Pond Aeration
  • Water Re-circulation
  • Ice Clearing / De-icing
  • Wastewater Lagoons
  • Fish hatcheries
  • Septic Tanks

Features

  • The simplest way to get air to your diffusers without ruining the aesethics of your pond.
  • Virtually invisible once it is connected and in place.
  • Extremely durable, does not kink and remains flexible even in cold weather.
  • This inside of the tubing has a smooth bore finish so there is less resistance which makes your aeration system more efficient.
  • Allows for easier installation, placement and maintenance of diffusers without the hassle of bricks and ties to keep tubing in place.

Read more Read Less

feature_image
faq-img

Specification

Construction

High density flexible PVC

Minimum Bend Radius

  • 1/4" ID: 2"
  • 3/8" ID: 3"
  • 1/2" ID: 4"
  • 5/8" ID: 5"
  • 3/4" ID: 7"

Dimensions

  • 1/4" ID x 0.55" OD
  • 3/8" ID x 0.687" OD
  • 1/2" ID x 1.0" OD
  • 5/8" ID x 1.12" OD
  • 3/4" ID x 1.36" OD

UV

UV Resistant

Maximum Pressure

50 psi

Temperature Range

25° F to 150° F (-4° C to 85° C)

Weight Per Foot

  • 1/4" ID: 0.14 pounds per foot
  • 3/8" ID: 0.20 pounds per foot
  • 1/2" ID: 0.44 pounds per foot
  • 5/8" ID: 0.51 pounds per foot
  • 3/4" ID: 0.76 pounds per foot

Warranty

1 year

Read more Read Less

FAQ

My compressor gets really hot. Will that be a problem? + -

Most installations will benefit from using a manifold such as the EasyPro ERP1V or a short section of heater hose to dissipate heat between the compressor and the self-sinking hose connection. 2-3 feet of heater hose is generally sufficient.

Is there any lead in the weighted tubing? + -

No. The tubing is constructed of High density flexible PVC. There is no lead in the product.

Will this work in salt water? How about a retention pond or wastewater lagoon? + -

Yes. MixAirTech Sinking Hose is suitable for any aquatic environment including freshwater, salt water, wastewater or retention ponds

What diameter hose should I purchase? + -

Larger tubing creates less friction & reduces back pressure.

Smaller diameter tubing works well for short, shallow runs; however as the length and/or number of diffusers increases, you will want to increase the diameter of the hose.

Does MixAir Sinking hose kink? + -

No. MixAir Sinking hose does not kink. It remains flexible in a wide range of temperatures and is designed to be maintenance-free while greatly reducing installation time.

Does MixAir Sinking Hose contain any metals? + -

No. All MixAir Sinking Hose is safe and metal free. It is specifically designed for & safe to use in ponds.

Can I use standard poly air tubing for some of the install? + -

Yes. Some installers will use less expensive tubing on shore and/or in the ground, and then switch to weighted tubing when they reach the water.

You can connect the different types of tubing with an appropriately-sized hose barb fitting and set of clamps from your local hardware store.

Can I bury MixAir sinking hose? + -

Yes. MixAir sinking hose is durable & it is a relatively common practice to bury hose between the compressor/manifold & diffusers.

Will the hose freeze up in the winter? + -

The hose itself will function fine in freezing temperatures, however if there is condensation or standing water in the line that can be problematic.

How deep should I bury the hose? + -

We recommend burying it below the frost line in your area - this prevents problems if standing water & condensation should form in the line during freezing temperatures.

What do you mean by UV Resistant? + -

The material was specifically designed to withstand harsh conditions subject to pond and lake aeration.

The material is UV resistant to help withstand UV rays and ensure product will maintain its performance characteristics.

Description

Weighted tubing carries air between the compressor and the diffuser. Made to work in all weather, even the cold, self-sinking hose will provide many years of service. Due to its weight, it will not float and requires no added weights during installation. Installation is easy and quick, compared to non-weighted tubing which requires added weights to keep it down.

Read more Read Less
